General ISO Geometrical Tolerances Per. ISO 2768The following are general geometrical tolerances per. ISO 2768 for the following:. Linear Dimensions. External Radius and Chamfer Heights. Straightness and Flatness. Perpendicularity.
Symmetry. RunoutRelated Mechanical Tolerance Design Data.Variations on dimensions without tolerance values are according to ' ISO 2768'.
All tolerance limits are given in mm.ISO 2768 and derivative geometrical tolerance standards are intendedto simplify drawing specifications for mechanical tolerances.
This chapter presents examples of restricted ranges of application of geometrical tolerances. The symmetry deviation is limited by the general tolerance. This limitation has no economical disadvantage, even when the function allows a random angular location, because the general tolerance is respected anyway without any additional effort.
Iso 2768-1
When drawing features are drawn on the same centre line, it is difficult to allocate different distance tolerances to the different features. Positional tolerancing, however, provides the possibility of allocating different tolerances to the different features.
Iso 2768 Hole Tolerance Symbol Download
The features of the patterns are drawn on different centre lines but symmetrically with respect to a symmetry line. From this, it is not quite obvious whether the tolerances apply simultaneously to the two patterns so that they form a single pattern to which a common gauge applies, or whether the tolerances apply separately to each pattern so that separate gauges apply to the patterns. When positional toleranced features are located symmetrically with respect to a symmetry line (common centre line), and it is not indicated whether the positional tolerances apply separately or simultaneously, it is recommended either to ask the designer what shall apply, or to use the failsafe method of simultaneous positional tolerances.
